PCB Circuit Board Assembly

PCB Circuit Board Assembly
PCB Circuit Board Assembly
PCB Circuit Board Assembly
PCB Circuit Board Assembly
PCB Circuit Board Assembly

Item specifics

Material
FR4
Board Thickness
1.6mm
Copper Thickness
1/1
Cover Film
green
Silkscreen Color
White
Surface Technics
ENIG (1-3u
Min Holes
0.2mm
Min Line space and width
6/6mil

Product review

Description

SENYAN main SMT production line consists of automated high-precision state-of-the-art equipments from Panasonic,Samsung,Japan total 6 lines(Smallest SMT components size can reach to 0201,capable of 0.6mm*0.3mm~50mm gap,+/-0.05 accuracy),Daily capacity can reach to 11,000,000 components.
Electronic Assembly Made capacity
Item
Capability
Item
Capability
Solder PastePrintig
Accuracy:±0.025mm
Wave Soldering
Nitrogen source:external
Max. speed:150mm/sec
Speed:5in² /sec (60FOV/sec)
PCB max. area:400*310mm
Temperature accuracy:±1°C
PCB thickness:0.2-6mm
Lead free compatible
SMT
Accuracy:±0.03mm
AOI
Accuracy:±0.0024mm
Speed:0.17sec/pc
Speed:5in² /sec (60FOV/sec)
PCB max. area:350*350mm
PCB max. area:300*300mm
Available part:0201 chip to 35*35mm
Available component:0201 chip and fine pitch
Accuracy:±0.05mm
PCB max. area:350*350mm
X-ray,Inspection
BGA void(0.5mm distance between Ball)
Available part:0402 chips to 14mm (H 12mm)
Minimum SMD resistor and capacitor:0201
Solderability inner shielding
Minimum BGA R-VTx:0.15mm
BGA Rework
Nitrogen source:NA
Nitrogen source:external
PCB max. size:350mm
Reflow Soldering
Nitrogen source:external
Temperature accuracy:±1°C
PCB max. size:400*330mm
Temperature accuracy:±4°C
Lead free compatible
Product Display
